Magnetic Proximity Switches

Magnetic Proximity Switches are designed to detect magnetic fields up to the distance of 60 mm. These can detect magnetic field even through ferromagnetic and non- ferromagnetic materials, it only depends on the power of permanent magnet. Furthermore, these magnetic proximity switches are extensively used for liquid level detection, monitoring of final position, stroke limitation in hydraulic cylinders etc.

Magnetic Proximity Switches are used to detect the magnetic field. it consist of two parts, one is the sensor and other is actuator. magnetic proximity sensors makes ancillary power unnecessary and makes the sensors and actuator combination the cost effective selection when compared to other sensing technologies. also offered in a non contact, piston detection sensor for use with steel hydraulic cylinders. magnetic sensors are easily mounted with out the need for mountingslotsor holes in cylinders.

some applications of magnetic proximity switches are-limit switching, machine tool position sensing, valve position sensing, food processing machinery, revolution sensing, elevator position sensing etc. . magnetic contacts are used as a door switch , rolling shutter and many more.


Magnetic Proximity Switches

Model no: PE-901

Our PE-901 magnetic proximity switch is CE approved and has 200 VDC of switching voltage. It is known for its compact design and easy usage. Furthermore, this proximity switch has contact resistance of 150 mOhm.


Model No PE-901
CONTACT RATING 10
SWITCHING VOLTAGE 200(VDC)
BREAKDOWN VOLTAGE 250(VDC)
SWITCHING CURRENT 500(m Amp.)
CONTACT RESISTANCE 150(m Ohm)
OPERATING TIME 1.0(mSec.)
OPERATING & STORAGE TEMP. -25To +75
MUST OPERATING DIS. 7(mm Max.)
MUST RELEASE DIS. 20(mm Min.)
APPROVAL CE Approved
Are You Interested For This Product?

Magnetic Proximity Switches

Model no: PE-902

Our PE-902 type magnetic proximity switch has operating and storage temperature ranging from -25 to +75. Moreover, it is known for its easy installation, less maintenance and optimum performance. These are available in Brass housing with diameter M8, M12 & M18 in NO and NC contact.


Model No PE-902
CONTACT RATING 10
SWITCHING VOLTAGE 200(VDC)
BREAKDOWN VOLTAGE 250(VDC)
SWITCHING CURRENT 500(m Amp.)
CONTACT RESISTANCE 150(m Ohm)
OPERATING TIME 1.0(mSec.)
OPERATING & STORAGE TEMP. -25To +75
MUST OPERATING DIS. 5(mm Max.)
MUST RELEASE DIS. 17(mm Min.)
APPROVAL CE Approved
Are You Interested For This Product?

Magnetic Proximity Switches

Model no: PE-903 (With LED Indication)

Our magnetic proximity switch of PE-903 (With LED Indication) type has must operating distance of 4 mm and must release distance of 15 mm. It is CE approved and 2.0 mSec of operating time. As well as avaiable in NO & NC Contacts.


Model No PE-903 (With LED Indication)
CONTACT RATING 20
SWITCHING VOLTAGE 300(VDC)
BREAKDOWN VOLTAGE 375(VDC)
SWITCHING CURRENT 750(m Amp.)
CONTACT RESISTANCE 100(m Ohm)
OPERATING TIME 2.0(mSec.)
OPERATING & STORAGE TEMP. -25To +75
MUST OPERATING DIS. 4(mm Max.)
MUST RELEASE DIS. 15(mm Min.)
APPROVAL CE Approved
Are You Interested For This Product?

Magnetic Proximity Switches

Model no: PE-904

Our range of magnetic proximity switches of PE-904 type is checked under various set quality parameters. It has switching voltage of 200 VDC and 250 VDC of breakdown voltage. As well as avaiable in NO & NC Contacts.


Model No PE-904
CONTACT RATING 10
SWITCHING VOLTAGE 200(VDC)
BREAKDOWN VOLTAGE 250(VDC)
SWITCHING CURRENT 500(m Amp.)
CONTACT RESISTANCE 150(m Ohm)
OPERATING TIME 1.0(mSec.)
OPERATING & STORAGE TEMP. -25To +75
MUST OPERATING DIS. 7(mm Max.)
MUST RELEASE DIS. 20(mm Min.)
APPROVAL CE Approved
Are You Interested For This Product?

Magnetic Proximity Switches

Model no: PE-905

This PE-905 type magnetic proximity switch is used to detect magnetic field emitting from permanent magnet. Furthermore, this proximity switch has the contact resistance of 150 mOhm.


Model No PE-905
CONTACT RATING 10
SWITCHING VOLTAGE 200(VDC)
BREAKDOWN VOLTAGE 250(VDC)
SWITCHING CURRENT 500(m Amp.)
CONTACT RESISTANCE 150(m Ohm)
OPERATING TIME 1.0(mSec.)
OPERATING & STORAGE TEMP. -25To +75
MUST OPERATING DIS. 5(mm Max.)
MUST RELEASE DIS. 15(mm Min.)
APPROVAL CE Approved
Are You Interested For This Product?

Magnetic Proximity Switches

Model no: PE-906

This magnetic proximity switch of PE-906 type has operating and storage temperature ranging from -25 to +75. It is CE approved and has contact rating 10. It is known for its excellent design and compact size.


Model No PE-906
CONTACT RATING 10
SWITCHING VOLTAGE 200(VDC)
BREAKDOWN VOLTAGE 250(VDC)
SWITCHING CURRENT 500(m Amp.)
CONTACT RESISTANCE 150(m Ohm)
OPERATING TIME 1.0(mSec.)
OPERATING & STORAGE TEMP. -25To +75
MUST OPERATING DIS. 7(mm Max.)
MUST RELEASE DIS. 20(mm Min.)
APPROVAL CE Approved
Are You Interested For This Product?

Magnetic Proximity Switches

Model no: PE-907

This PE-907 magnetic proximity switch has switching voltage of 200 VDC. It is precisely designed by using advance technology. Furthermore, it is known to found various industrial applications. It is widely used as door services in security system


Model No PE-907
CONTACT RATING 10
SWITCHING VOLTAGE 200(VDC)
BREAKDOWN VOLTAGE 250(VDC)
SWITCHING CURRENT 500(m Amp.)
CONTACT RESISTANCE 150(m Ohm)
OPERATING TIME 1.0(mSec.)
OPERATING & STORAGE TEMP. -25To +75
MUST OPERATING DIS. 5(mm Max.)
MUST RELEASE DIS. 20(mm Min.)
APPROVAL CE Approved
Are You Interested For This Product?

Magnetic Proximity Switches

Model no: PE-908

Our range of magnetic proximity switch of PE-908 type has contact resistance of 75 mOhm. This proximity sensor is highly appreciated amongst customers for its easy installation.


Model No PE-908
CONTACT RATING 50
SWITCHING VOLTAGE 450(VDC)
BREAKDOWN VOLTAGE 500(VDC)
SWITCHING CURRENT 1000(m Amp.)
CONTACT RESISTANCE 75(m Ohm)
OPERATING TIME 5.0(mSec.)
OPERATING & STORAGE TEMP. -25To +75
MUST OPERATING DIS. 3.5(mm Max.)
MUST RELEASE DIS. 10(mm Min.)
APPROVAL CE Approved
Are You Interested For This Product?
